Fortinet FortiGate 120G

Overview

The FortiGate 120G is a next-generation firewall (NGFW) designed to provide robust security for distributed enterprise sites and transform WAN architecture at any scale. It integrates advanced threat protection with high-performance hardware acceleration, ensuring secure and efficient network operations.

Features

• High-Performance Security:
  Equipped with Fortinet's SP5 hardware acceleration, delivering exceptional throughput and low latency for enterprise networks.
• Comprehensive Connectivity:
  Features 18 Gigabit Ethernet RJ45 ports (including 1 management and 1 HA port), 8 Gigabit Ethernet SFP slots, and 4 10 Gigabit Ethernet SFP+ slots, offering versatile connectivity options.
• Dual AC Power Supplies:
  Designed with dual non-hot swappable AC power supplies to ensure uninterrupted service and operational reliability.
• Integrated Security Fabric:
  Part of Fortinet’s Security Fabric, providing advanced threat protection, real-time SSL inspection, and AI-powered FortiGuard services.
• Streamlined Network Management:
  Supports FortiLink protocol for seamless integration of security and network management, enabling centralized control across all networked FortiGate devices.

Specifications

• Form Factor:
  1U rack-mountable appliance.
• Dimensions:
  Width: 43.2 cm (17 inches)
  Height: 4.4 cm (1.73 inches)
  Depth: 25.4 cm (10 inches)
  Weight: 5.52 kg (12.2 lbs)
• Networking Interfaces:
• 18 x 1000Base-T RJ-45 ports
• 8 x 1000Base-X SFP slots
• 4 x 10GBase-X SFP+ slots
• 1 x USB 3.0 Type A port
• 1 x console port (RJ-45)
• Performance Metrics:
• Firewall Throughput: 39 Gbps
• NGFW Throughput: 3.1 Gbps
• Threat Protection Throughput: 2.8 Gbps
• IPS Throughput: 5.3 Gbps
• SSL VPN Throughput: 1.5 Gbps
• Concurrent Sessions: 3 million
• New Sessions per Second: 140,000
• Firewall Latency: 3.17 µs
• Power Specifications:
• Dual internal AC power supplies
• Power Consumption: 38 Watts
• Voltage Required: AC 100-120 V (50/60 Hz)
• Environmental Parameters:
• Operating Temperature: 0°C to 40°C
• Operating Humidity: 20% to 90% (non-condensing)
• Compliance Standards:
  FCC Part 15 B Class A, RCM, VCCI, UL, cUL, CB, BSMI, USGv6
