Overview
The Cisco Catalyst 9300X 24Y (C9300X-24Y-A) is a high-performance, enterprise-class access switch designed for modern campus and data center networks. It provides 24 high-speed 25G fiber ports for connecting servers, uplinks, and high-bandwidth devices.
The switch delivers advanced Layer 2 and Layer 3 features, integrated security, and automation capabilities. With Cisco DNA Center integration, it enables policy-driven management, network assurance, and simplified operations, making it ideal for high-performance enterprise access and aggregation deployments.
Key Features
- 24 × 25G fiber ports for high-speed connectivity and server uplinks
- High-performance Layer 2 and Layer 3 switching for enterprise networks
- Stackable design with Cisco StackWise technology for scalability
- Integration with Cisco DNA Center for automation, analytics, and network assurance
- Advanced security features including 802.1X, access control lists, and segmentation
- Redundant power supply and hot-swappable fan options for high availability
- Energy-efficient design optimized for dense deployments
- QoS, traffic shaping, and application-aware routing support
- Suitable for enterprise access layer, aggregation, and high-speed uplink scenarios
Specifications
Specification
Detail
Model
C9300X-24Y-A
Port Density
24 × 25G SFP28 fiber ports
Uplink Options
4 × 40/100G QSFP28 ports
Switching Capacity
Up to 1.2 Tbps per switch
Forwarding Rate
Up to 890 Mpps
Layer 2 Features
VLANs, STP, VTP, Private VLANs, port channels
Layer 3 Features
OSPF, EIGRP, BGP, IS-IS, static routing, VRF support
High Availability
StackWise-480, redundant power supply, hot-swappable fans
Management / Monitoring
Cisco DNA Center, Cisco IOS XE CLI, SNMP, NetFlow, telemetry
Form Factor
1RU rackmount, stackable
Dimensions (W × H × D)
440 mm × 44 mm × 500 mm
Weight
Approx. 13 kg
Power Supplies
Dual hot-swappable PSU options
Operating Temperature
0 °C to 45 °C
Certifications
CE, FCC, UL, RoHS
Use Cases / Workload Fit
Enterprise access layer, high-speed uplinks, aggregation, server connectivity
Warranty / Support Options
Standard Cisco warranty; optional extended service and support plans available
