Dell EMC PowerProtect DD6900

Overview

The Dell EMC PowerProtect DD6900 is an enterprise-grade data protection appliance designed to deliver high-performance backup and recovery solutions. As part of the Dell EMC PowerProtect Data Domain series, it offers scalable storage capabilities, efficient data reduction, and robust security features, making it ideal for modern IT environments seeking reliable data protection.

Features

• High-Performance Backup and Recovery: Achieves up to 15 TB/hr throughput, ensuring rapid data protection operations.
• Scalability: Supports usable capacities ranging from 24 TB to 288 TB, with cloud tiering capabilities extending logical capacity up to 56.1 PB.
• Advanced Data Reduction: Delivers up to 65:1 data reduction, optimizing storage efficiency.
• Integrated Cloud Tiering: Seamlessly integrates with cloud storage solutions, enhancing data mobility and disaster recovery options.
• Cyber Resilience: Incorporates security features to protect against ransomware and other cyber threats.
• Simplified Management: Offers intuitive management interfaces for streamlined operations and monitoring.

Specifications

• Processor: Dual Intel Xeon 4208, 8 cores, 2.10 GHz.
• Memory: Total of 288 GB, configured with 12 x 8 GB and 12 x 16 GB DIMMs.
• Storage:
• Active Tier: 4 TB HDDs.
• Cloud Tier Metadata: 4 TB.
• Supported Capacity:
• Active Tier: 22 TB to 280 TB.
• Cloud Tier: Up to 576 TB.
• Disk Groups:
• Active Tier: 1 to 6 groups (4 TB).
• Cloud Tier: 1 to 2 groups (4 TB).
• Operating System: Dell EMC Data Domain Operating System (DD OS) version 4.4.
• Form Factor: Rack-mounted appliance.
• Weight: Approximately 63.05 lbs (28.6 kg).
• Operating Environment:
• Temperature: 50° to 95° F (10° to 35° C).
• Humidity: 20% to 80%, non-condensing.
• Acoustic Noise: LwAd sound power level of 7.5 Bels.
